Function
Standard fitting：
A.Automatically test regular pressure gauges, precise pressure gauges, electro connecting pressure gauges, pressure controller, pressure transducer and pressure sensors etc according to the newest national testing regulation.
B.Half automatically test digital pressure gauges according the newest national testing regulation.
C.With half automatic test function, can test the pressure gauges with obvious defect on the display plate & scale mark.
D.Automatically handle the testing data and do the judgement.
E.Can display and print the history record, including the form of error on each tested point, all kinds of display value error required to be tested in the regulation, and judge the test result accordingly.
F.Can do the search and management of the testing record according to the style of the gauge, manufacture unit, manufacturing number, operator, test sending unit, facility code, testing date and expire date etc.
G.Can choose many records from the data base, print the test record and certification centrally.
H.Can output the test data into WORD file.
Optional fitting：
Can make testing record form and form of testing certificate according to the customer’s special requirement.
Technical parameter
1.Calibrate range：（0～60)MPa
2.Calibrate range：regular pressure gauges, precise pressure gauges, electro connecting pressure gauges, digital pressure gauge, pressure controller, pressure transducer and pressure sensors etc.
3.Pressure measure precision: ±0.05% F.S
4.CCD auto reading gauge precision：better than 0.1 box
5.Auto test speed: 15s/point ～ 25s/point
6.CCD& q’ty of gauges：2 CCD，test 2 gauges or transducers one time
7.Current and voltage measure precision： ±（0.03%RD+0.02%F.S）
8.Current and voltage measurement：cover whole range from -50V to 50V, auto range switchover.
9.Current and voltage measurement: range from -22mA to 22mA, realize most of measure requirement.
10.DC24V or 1.5mA output: precision＜5%F.S
11.Power supply： 220V 50Hz
12.Working circumstance：temperature：20±5℃，relative humidity：50～70%RH
13.Special design: leakage proof, filter and easy to disassemble
14.Dimension and weight：450×320 ×240(mm) , 35kg
