Features
For dial indicators,dial comparators,inside micrometers,lever-type indicators,digital dial indicators and etc.
Can be used horizontally and vertically.
Electronic handwheel for manual control of the measuring spindle's movement.
Self-adjusting sensitivity of the electronic handwheel for adaptation to the specific test specimen.
Equipped with motorized drive and accurate grating shifting measurement and control technology system to ensure the efficient and precise metrology automatically.
The completely software controlled test run.High speed testing process, 10-200 seconds/pc for testing.
Powerful software management functions including displaying and print history records,inquiry and calculate record results,customized testing report form and testing certificate form,customized measurement standard or testing regulation.
CCD image processing system.
Semi-auto testing function for dial indicators with stains.
Camera stand can be set horizontally or vertically,easy to pack and bring.
Simple operation,just fix the dial indicator and choose the parameters like the type of indicator,the resolution and dial range etc,and then click "start to test",the tester will work immediately.
Specifications
Working Environment: temperature (20±2）℃, humidity (50-70)%RH
Measuring range: 0-50mm
Resolution: 0.1μm
Repeatability: 0.1μm
Positioning speed: 0.5-0.8s/point
Indication error: 1mm≤1.0μm，2mm≤1.2μm，10mm≤1.5μm，
30mm≤1.8μm，50mm≤2.5μm
Hysterisis error: ≤0.5μm
Computer interface: RS232 or USB
Display panel: LED
Supply voltage: AC 110-240V, 50-60Hz
Dimension: 640*240*530 mm
Weight: 35kg
